Cyberpower OR1500ERM1U Rack Mountable UPS 1U 6xC13 1500VA/900W

613.77
SKU: OR1500ERM1U Categories: ,

Cyberpower OR1500ERM1U Rack Mountable UPS 1U 6xC13 1500VA/900W

CyberPower OR1500ERM1U Line-Interactive UPS offers Simulated Sine Wave output power for office system devices including PCs, workstations, networking devices, and peripherals. It’s typically integrated in the back office and server room environment to ensure a reliable backup power supply during power failures. The UPS has a multifunction LCD display which offers real-time information, including input and output voltage levels, load and battery levels, battery runtime, overload warning, and a silent mode. With the network ports on the UPS, it prevents network devices from being subjected to sudden power surges caused by lightning, thereby avoiding potential system damage. As for battery maintenance, the UPS allows battery hot-swapping, which enables users to perform normal battery maintenance without significant interruption.

  • Line-interactive UPS Topology
  • Simulated Sine Wave Output
  • Overload Protection
  • Surge and Spike Protection
  • LCD Status Display
  • PowerPanel Management Software
  • Energy Saving Technology
  • Automatic Voltage Regulation (AVR)
  • Hot-swappable Batteries
  • EMI and RFI Filtration
  • USB Connectivity Port
  • SNMP/HTTP Remote Management Capability (Optional)

General

Phase

Single Phase
Form Factor

Rackmount
UPS Topology

Line-interactive
Energy Saving Technology

GreenPower UPS™ Bypass Technology

Input

Nominal Input Voltage ( Vac )

220
230
240
Input Voltage Range ( Vac )

165 ~ 271
Adjustable Voltage Range ( Vac )

253 ~ 271 Vac
189 ~ 207 Vac
Input Frequency ( Hz )

50 ± 3
60 ± 3
Input Frequency Detection

Auto-sensing
Input Connector Type

IEC C14
Detachable Power Cord Plug Type

IEC C14 x 1
Power Cord Length (ft.)

6
Power Cord Length (m.)

1.83

Output

Capacity (VA)

1500
Capacity (Watts)

900
On Battery Waveform

Simulated Sine Wave
On Battery Voltage(s) ( Vac )

230 ± 10 %
On Battery Frequency ( Hz )

50 ± 1%
60 ± 1%
Power Factor

0.6
Automatic Voltage Regulation (AVR)

Single Boost
Overload Protection

Internal Current Limiting, Circuit Breaker
Outlet(s) – Total

6
Outlet Type

IEC C13 x 6
Outlet(s) – Battery & Surge Protected

4
Outlet(s) – Surge-Only Protected

2
Typical Transfer Time ( ms )

4

Battery

Runtime at Half Load ( min )

11
Runtime at Full Load ( min )

2.5
Typical Recharge Time ( Hours )

8
Start On Battery

Yes
User-replaceable

Yes
Hot-swappable

Yes
Battery Type

Sealed Lead-acid
Replacement Battery Pack (RBP)

RBP0026
Replacement Battery Pack (RBP) Quantity ( pcs )

1

Surge Protection & Filtering

Surge Suppression ( Joules )

810
EMI/RFI Filtration

Yes
Network Protection RJ45

1-in, 1-out

Management & Communications

LCD Panel

Yes
LCD Information Display

Operation Type, Power Status, Battery Status, Load Status, Other Information
LCD Setting & Control

Mode Setting, Alarm Setting, Input & Output
LED Indicators

Power On
HID Compliant USB Port(s)

1
Serial Port

Dry Contact
Audible Alarms

Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs )

Power Cord x4, USB Cable x1
Power Management Software

PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring

Yes – with optional RMCARD205

Physical

Enclosure Construction

Metal
Color

Silver
Rackmount Ears

Yes

Physical Size – UPS Module

Dimensions (WxHxD) (in.)

17 x 1.7 x 15.3
Dimensions (WxHxD) (mm.)

433 x 44 x 389
Weight (lbs.)

32.8
Weight (kg.)

14.9
Installed Rack Height ( U )

1

Environmental

Operating Temperature (°F)

32 ~ 104
Operating Temperature (°C)

0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )

0 ~ 95
Operating Elevation ( feet/meters )

0-9,843 feet (0-3,000 meters)
Storage Temperature (°F)

5 ~ 113
Storage Temperature (°C)

-15 ~ 45
Storage Relative Humidity (Non-condensing) ( % )

0 ~ 95
Storage Elevation ( feet/meters )

0-49,213 feet (0-15,000 meters)
Online Thermal Dissipation ( BTU/hr )

24

Certifications

Certifications

CE, EAC, RCM
RoHS

Yes

WARRANTY

Product Warranty Period (Year)

2
Battery Warranty Period (Year)

2
