Key Features
-
867 Mbps throughput over 5 GHz (Wi-Fi 5, 2×2 MIMO)
-
120° wide coverage with a 15 dBi directional antenna (13° vertical beamwidth)
-
Up to 5 km range with clear line-of-sight
-
Supports up to 16 CPEs in PTMP setup
-
3× Gigabit Ethernet ports, with 802.3af/at PoE support
-
Cloud & local management with built-in deployment tools:
-
One-click pairing
-
Alignment Assistant
-
Spectrum Scan
-
Technical Overview
| Feature | Specification |
|---|---|
| Wireless Standard | IEEE 802.11ac (Wi-Fi 5), 802.11ac/n/g/b |
| Frequency Band | 5.15 – 5.85 GHz (main), 2.4 GHz (management) |
| Max Wireless Speed | 867 Mbps (5 GHz), 150 Mbps (2.4 GHz) |
| Antenna Gain | 15 dBi directional antenna |
| Beamwidth | 120° horizontal, 13° vertical |
| Max Link Distance | Up to 5 km |
| Max Connected CPEs | 16 |
| Ethernet Ports | 3× Gigabit RJ45 |
| PoE Support | 802.3af/at, Passive PoE, or 12 V DC input |
| Management Interface | Web, Cloud (Reyee App), SON-enabled |
| Operating Temp | –40 °C to +80 °C |
| Protection | IP55 weatherproof, ESD 15 kV |
| Mounting | Pole mount included |
