Lan speed | 10/100 Mbps |
Dimensions | 87 × 44 × 29.2 mm |
Weight | 92 g |
Output voltage | 24VDC @ 0.5A |
LAN activity indicator | No |
Gigabit LAN port | No |
Remote resetting capability | Yes |
Reset button | Yes |
Input voltage | 90-260VAC @ 47-63 Hz |
Input current | 0.3A @ 120VAC, 0.2A @ 240VAC |
Inrush current | <30A Peak @120VAC, <60A Peak @ 230VAC |
Effectiveness | 75+% |
Output current pulsation | 1% Max. |
Switching frequency | 50 kHz |
Linear adjustment | ± 1% |
Load adjustment | ± 3% |
2 steam power supply | Pins 4, 5 (+) and Pins 7, 8 (-) |
Operating temperature | 0 to 40° C |
Storage temperature | -30 to 70°C |
Humidity during operation | 35 to 95% |
AC connector | IEC-320 C6 |
Date IN / POE | RJ45 , shielded socket |
Surge protection | Modes: Difference and Common |
Clamp protections | 11 V Data, 60 V Power |
Highest pulse rate | 36A (10/1000µS) Date |
Electric capacity of the shunt | <5 pf date |
Response time | <1 nS |
Compatibility | IEC 60950-1:2005+A1 UL60950-1EN55022:2010, EN55024:2010 FCC Class B |
AC cable | Not Included |
