WiFi Technology

• Standard: WiFi 7 (802.11be)

• Spatial Streams: 4

• Max Data Rate:

  • 5 GHz: Up to 4.3 Gbps (BW240)

  • 2.4 GHz: Up to 688 Mbps (BW40)

• Antenna Gain:

  • 5 GHz: 5 dBi

  • 2.4 GHz: 4 dBi

• MIMO Technology: 2×2 MU-MIMO (DL/UL) for both 2.4 and 5 GHz

• Max TX Power:

  • 5 GHz: 24 dBm

  • 2.4 GHz: 23 dBm

• Coverage Area: Up to 115 m² (1,250 ft²)

• Max Client Capacity: 200+ concurrent users

Networking & Power

• Uplink Interface: 1x 2.5 GbE RJ45 port

• Power Consumption: Max. 13W

• Voltage Range: 42.5–57V DC

Advanced Features

• Wireless Meshing

• Band Steering, Fast Roaming (802.11r), BSS Transition (802.11v), and RRM (802.11k)

• Hotspot Capabilities: Captive portal with custom branding, voucher and payment-based authentication, PPSK, and external portal server support

• Security & Access Control: Guest network isolation, client device isolation, RADIUS over TLS (RadSec), dynamic VLANs

• Network Management: WiFi scheduling, bandwidth limiting, and advanced radio management

Software & Management

• Platform Compatibility:

  • UniFi Network: Version 9.0.114+

  • Mobile Apps:

    • iOS™ 10.20.2+

    • Android™ 10.21.7+

• Enclosure: UV-stabilized polycarbonate

• Status LED: White/Blue system indicator

• Compliance: NDAA-compliant; certified CE, FCC, IC

Environmental Tolerance

• Operating Temperature: -30°C to 40°C (-22°F to 104°F)

• Humidity: 5% to 95% non-condensing
